Mathematically Describing Neuronal Connections in the Brain

Students in my classes have started to catch on to the fact that I tend to dress up for lectures I am particularly excited about. For a topic I'm indifferent toward or lukewarm about, I wear my standard dress shirt, slacks, and dress shoes. To prepare for a subject I like a little bit more, that's when I throw on a sports jacket, and possibly a nice belt. But get me all hot and bothered, and that's when I break out...the ties.

Not surprisingly, then, I wear a three-piece suit when talking about neurons. These sexy little suckers act as the basic cells of communication throughout your brain and throughout your nervous system, relaying electrical transmissions all the way down your axons to the synaptic gap, those terminal buttons precariously poised on the precipice of a protoplasmic kiss, until finally, excruciatingly, those tiny vesicles of chemical bliss burst from their vile durance, recrudescent, crushing out the last throb of the last ecstasy man or monster has ever known.

...Let me catch my breath...Where was I? Oh yes - neurons. Besides their role in transmitting electrical and chemical signals throughout the brain, they also exist in astonishingly high numbers, with somewhere on the order of tens of billions of neurons packed into a single brain. On top of this, each one can share hundreds or thousands of connections with other neurons, leading to a staggering number of potential synaptic connections. The mind boggles.

To provide the full mathematical treatment of understanding neurons, we are joined again by Keith "The Rookie" Bartley, whose interest in synaptic connections was recently piqued by an introductory cognitive science course. Along the way Keith touches on mathematics, the Turing Test, Friends, oatmeal, the uncanny valley, and where genitals are represented in the brain, providing a theoretical basis for why foot massages can lead to greater chances for successful coitus.

==============

As a TA for an Introduction to Cognitive Science course, one of our instructors briefly discussed the concept of Block's "Aunt Bertha Machine" and how the Turing test alone required more bits of memory than there are atoms in the universe. (If you aren't familiar with Ned Block's work click here).  Below is a section of one of his slides:

Volume: (15*10^9 light-years)^3 = (15*10^9*10^16 meters)^3
Density: 1 bit per (10^-35 meters)^3
Total storage capacity: 10^184 bits < 10^200 bits < 2^670 bits
Critical Turing Test length: 670 bits < 670 characters < 140 words < 1 minute

Difficult as it is for some people to conceptualize and subsequently deal with such induced feelings of simultaneous intelligence, stupidity, and insignificance pervading recapitulations of their own life's meaning, I would like to warn those people that the following information about the capacity of the human brain is likely to do much worse. READ RESPONSIBLY.

For the human brain, the possible number of combinations and permutations of neural connections has been purported to vastly exceed the number of elementary particles in the Universe. Consider for a moment that the brain has 85,000,000,000 neurons, we'll round that up to the previously estimated 100,000,000,000 for hypothetical simplicity, each with a capacity for up to 10,000 synaptic "connections".

1! = 1
10! = 3,628,800
100! = 9.33 x 10^157
1000! = 4.02 x 10^2,567
***This is where Google's calculator starts to report infinity***

For bigger factorials, we'll have to use Stirling's approximation.

Stirling MATLAB Code

So using Stirling's approximation....

10,000,000,000! ~ 2.33 x 10^95,657,055,186
100,000,000,000! ~ 3.75 x 10^1,056,570,551,815

But wait, each of the 100 billion neurons can have 10,000 synaptic connections, so…

10^11 * 10,000 = 1e26

So rather...

100,000,000,000,000,000,000,000,000! ~ REALLY BIG NUMBER

But Keith! Come on, this looks like a gross misrepresentation of the limits of human cognition?


Our theories about the brain are much more modular in scope, but at the same time, distributed enough to adapt. These two points function as a much better descriptor of the networked brain. It's reasonable to see, in our post-Scopes trial times, that humans' brains developed around how they are utilized in their day-to-day lives, and perhaps more importantly, the phenomenal ability to constantly adapt, even in the wake of extreme trauma. The development and existence of a single "grandmother neuron", is misrepresentative of our degree of sustainability in the brain. Neurons for your grandmother have to be very distributed, so that when some of your brains cells die off, as they often do, it's important you don't forget the old woman that squeezes your cheeks when she sees you, lest you punch her in the face for assault. Jennifer Aniston would no longer instill memories of how much time you wasted watching reruns of Friends on TBS every afternoon for 4 years, and Halle Berry would no longer remind you of how Hollywood reduced one of the greatest antiheroines in the history of DC Comics to a mannequin in spandex with a speech impediment.

At the same time, however, that three pounds of oatmeal between your ears still retains a relative degree of modularity in regional function, which is a reason why your brain is compartmentalized in various folds (gyri) and crevices (sulci). When you have an itch from what is in fact a really small bug bite, your desired area to itch is very distributed across skin because the signals in the brain are themselves both distributed and modular. A diagram often used to demonstrate this modularity is the cortical homunculus.

Straight out of the backwoods of the uncanny valley, this diagram demonstrates the relative intensity and location that each section along your somatosensory cortex corresponds with on your body. As for the proximity of feet relative to your genitals, well that might just explain a lot about some guys now wouldn't it.

Introduction to Computational Modeling: Hodgkin-Huxley Model

Computational modeling can be a tough nut to crack. I'm not just talking pistachio-shell dense; I'm talking walnut-shell dense. I'm talking a nut so tough that not even a nutcracker who's cracked nearly every damn nut on the planet could crack this mother, even if this nutcracker is so badass that he wears a leather jacket, and that leather jacket owns a leather jacket, and that leather jacket smokes meth.

That being said, the best approach to eat this whale is with small bites. That way, you can digest the blubber over a period of several weeks before you reach the waxy, delicious ambergris and eventually the meaty whale guts of computational modeling and feel your consciousness expand a thousandfold. And the best way to begin is with a single neuron.


The Hodgkin-Huxley Model, and the Hunt for the Giant Squid

Way back in the 1950s - all the way back in the twentieth century - a team of notorious outlaws named Hodgkin and Huxley became obsessed and tormented by fevered dreams and hallucinations of the Giant Squid Neuron. (The neurons of a giant squid are, compared to every other creature on the planet, giant. That is why it is called the giant squid. Pay attention.)

After a series of appeals to Holy Roman Emperor Charles V and Pope Stephen II, Hodgkin and Huxley finally secured a commission to hunt the elusive giant squid and sailed to the middle of the Pacific Ocean in a skiff made out of the bones and fingernails and flayed skins of their enemies. Finally spotting the vast abhorrence of the giant squid, Hodgkin and Huxley gave chase over the fiercest seas and most violent winds of the Pacific, and after a tense, exhausting three-day hunt, finally cornered the giant squid in the darkest netherregions of the Marianas Trench. The giant squid sued for mercy, citing precedents and torts of bygone eras, quoting Blackstone and Coke, Anaxamander and Thales. But Huxley, his eyes shining with the cold light of purest hate, smashed his fist through the forehead of the dread beast which erupted in a bloody Vesuvius of brains and bits of bone both sphenoidal and ethmoidal intermixed and Hodgkin screamed and vomited simultaneously. And there stood Huxley triumphant, withdrawing his hand oversized with coagulate gore and clutching the prized Giant Squid Neuron. Hodgkin looked at him.

"Huxley, m'boy, that was cold-blooded!" he ejaculated.
"Yea, oy'm one mean cat, ain't I, guv?" said Huxley.
"'Dis here Pope Stephen II wanted this bloke alive, you twit!"
"Oy, not m'fault, guv," said Huxley, his grim smile twisting into a wicked sneer. "Things got outta hand."


Scene II

Drunk with victory, Hodgkin and Huxley took the Giant Squid Neuron back to their magical laboratory in the Ice Cream Forest and started sticking a bunch of wires and electrodes in it. To their surprise, there was a difference in voltage between the inside of the neuron and the bath surrounding it, suggesting that there were different quantities of electrical charge on both sides of the cell membrane. In fact, at a resting state the neuron appeared to stabilize around -70mV, suggesting that there was more of a negative electrical charge inside the membrane than outside.

Keep in mind that when our friends Hodgkin and Huxley began their quest, nobody knew exactly how the membrane of a neuron worked. Scientists had observed action potentials and understood that electrical forces were involved somehow, but until the experiments of the 1940s and '50s the exact mechanisms were still unknown. However, through a series of carefully controlled studies, the experimenters were able to measure how both current and voltage interacted in their model neuron. It turned out that three ions - sodium (Na+), potassium (K+), and chlorine (Cl-) - appeared to play the most important role in depolarizing the cell membrane and generating an action potential. Different concentrations of the ions, along with the negative charge inside the membrane, led to different pressures exerted on each of the ions.

For example, K+ was found to be much more concentrated inside of the neuron than outside, leading to a concentration gradient exerting pressure for the K+ ions to exit the cell; at the same time, however, the attractive negative force inside the membrane exerting a countering electrostatic pressure, as positively charged potassium ions would be drawn toward the inside of the cell. Similar characteristics of the sodium and chlorine ions were observed as well, as shown in the following figure:

Ned the Neuron, filled with Neuron Goo. Note that the gradient and electrostatic pressures, expressed in microvolts (mV) have arbitrary signs; the point is to show that for an ion like chlorine, the pressures cancel out, while for an ion like potassium, there is slightly more pressure to exit the cell than enter it. Also, if you noticed that these values aren't 100% accurate, then congratu-frickin-lations, you're smarter than I am, but there is no way in HECK that I am redoing this in Microsoft Paint.

In addition to these passive forces, Hodgkin and Huxley also observed an active, energy-consuming force in maintaining the resting potential - a mechanism which exchanged potassium for sodium ions, by kicking out roughly three sodium ions for each potassium ion. Even with this pump though, there is still a whopping 120mV of pressure for sodium ions to enter. What prevents them from rushing in there and trashing the place?

Hodgkin and Huxley hypothesized that certain channels in the neuron membrane were selectively permeable, meaning that only specific ions could pass through them. Furthermore, channels could be either open or closed; for example, there may be sodium channels dotting the membrane, but at a resting potential they are usually closed. In addition, Hodgkin and Huxley thought that within these channels were gates that regulated whether the channel was open or closed, and that these gates could be in either permissive or non-permissive states. The probability of a gate being in either state was dependent on the voltage difference between the inside and the outside of the membrane.

Although this all may seem conceptually straightforward, keep in mind that Hodgkin and Huxley were among the first to combine all of these properties into one unified model - something which could account for the conductances, voltage, and current, as well as how all of this affected the gates within each ion channel - and they were basically doing it from scratch. Also keep in mind that these crazy mofos didn't have stuff like Matlab or R to help them out; they did this the old-fashioned way, by changing one thing at a time and measuring that shit by hand. Insane. (Also think about how, in the good old days, people like Carthaginians and Romans and Greeks would march across entire continents for months, years sometimes, just to slaughter each other. Continents! These days, my idea of a taxing cardiovascular workout is operating a stapler.) To show how they did this for quantifying the relationship between voltage and conductance in potassium, for example, they simply applied a bunch of different currents, saw how it changed over time, and attempted to fit a mathematical function to it, which happens to fit quite nicely when you include n-gates and a fourth-power polynomial.

After a series of painstaking experiments and measurements, Hodgkin and Huxley calculated values for the conductances and equilibrium voltages for different ions. Quite a feat, when you couple that with the fact that they hunted down and killed their very own Giant Squid and then ripped a neuron out of its brain. Incredible. That is the very definition of alpha male behavior, and it's something I want all of my readers to emulate.

Table 3 from Hodgkin & Huxley (1952) showing empirical values for voltages and conductances, as well as the capacitance of the membrane.

The same procedure was used for the n, m, and h gates, which were also found to be functions of the membrane voltage. Once these were calculated, then the conductances and voltage potential could be found for any resting potential and any amount of injected current.

H & H's formulas for the n, m, and h gates as a function of voltage.

So where does that leave us? Since Hodgkin and Huxley have already done most of the heavy lifting for us, all we need to do is take their constants and equations they've already derived, and put it into a script that we can then run through Matlab. At some point, just to get some additional exercise, we may also operate a stapler.

But stay focused here. Most of the formulas and constants can simply be transcribed from their papers into a Matlab script, but we also need to think about the final output that we want, and how we are going to plot it. Note that the original Hodgkin and Huxley paper uses a differential formula for voltage to tie together the capacitance and conductance of the membrance, e.g.:

We can use a method like Euler first-order approximation to plot the voltages, in which each time step is based off of the previous one which is added to a function multiplied by a time step; in the sample code below, the time step can be extremely small, thus giving a better approximation to the true shape of the voltage timecourse. (See the "calculate the derivatives" section below.)

The following code runs a simulation of the Hodgkin Huxley model over 100 milliseconds with 50mA of current, although you are encouraged to try your own and see what happens. The sample plots below show the results of a typical simulation; namely, that the voltage depolarizes after receiving a large enough current and briefly becomes positive before returning to its previous resting potential. The conductances of sodium and potassium show that the sodium channels are quickly opened and quickly closed, while the potassium channels take relatively longer to open and longer to close.The point of the script is to show how equations from papers can be transcribed into code and then run to simulate what neural activity should look like under certain conditions. This can then be expanded into more complex areas such as memory, cognition, and learning.

The actual neuron, of course, is nowhere to be seen; and thank God for that, else we would run out of Giant Squids before you could say Jack Robinson.


Resources
Book of GENESIS, Chapter 4
Original Hodgkin & Huxley paper


%===simulation time===
simulationTime = 100; %in milliseconds
deltaT=.01;
t=0:deltaT:simulationTime;


%===specify the external current I===
changeTimes = [0]; %in milliseconds
currentLevels = [50]; %Change this to see effect of different currents on voltage (Suggested values: 3, 20, 50, 1000)

%Set externally applied current across time
%Here, first 500 timesteps are at current of 50, next 1500 timesteps at
%current of zero (resets resting potential of neuron), and the rest of
%timesteps are at constant current
I(1:500) = currentLevels; I(501:2000) = 0; I(2001:numel(t)) = currentLevels;
%Comment out the above line and uncomment the line below for constant current, and observe effects on voltage timecourse
%I(1:numel(t)) = currentLevels;


%===constant parameters===%
%All of these can be found in Table 3
gbar_K=36; gbar_Na=120; g_L=.3;
E_K = -12; E_Na=115; E_L=10.6;
C=1;


%===set the initial states===%
V=0; %Baseline voltage
alpha_n = .01 * ( (10-V) / (exp((10-V)/10)-1) ); %Equation 12
beta_n = .125*exp(-V/80); %Equation 13
alpha_m = .1*( (25-V) / (exp((25-V)/10)-1) ); %Equation 20
beta_m = 4*exp(-V/18); %Equation 21
alpha_h = .07*exp(-V/20); %Equation 23
beta_h = 1/(exp((30-V)/10)+1); %Equation 24

n(1) = alpha_n/(alpha_n+beta_n); %Equation 9
m(1) = alpha_m/(alpha_m+beta_m); %Equation 18
h(1) = alpha_h/(alpha_h+beta_h); %Equation 18


for i=1:numel(t)-1 %Compute coefficients, currents, and derivates at each time step

    %---calculate the coefficients---%
    %Equations here are same as above, just calculating at each time step
    alpha_n(i) = .01 * ( (10-V(i)) / (exp((10-V(i))/10)-1) );
    beta_n(i) = .125*exp(-V(i)/80);
    alpha_m(i) = .1*( (25-V(i)) / (exp((25-V(i))/10)-1) );
    beta_m(i) = 4*exp(-V(i)/18);
    alpha_h(i) = .07*exp(-V(i)/20);
    beta_h(i) = 1/(exp((30-V(i))/10)+1);


    %---calculate the currents---%
    I_Na = (m(i)^3) * gbar_Na * h(i) * (V(i)-E_Na); %Equations 3 and 14
    I_K = (n(i)^4) * gbar_K * (V(i)-E_K); %Equations 4 and 6
    I_L = g_L *(V(i)-E_L); %Equation 5
    I_ion = I(i) - I_K - I_Na - I_L;


    %---calculate the derivatives using Euler first order approximation---%
    V(i+1) = V(i) + deltaT*I_ion/C;
    n(i+1) = n(i) + deltaT*(alpha_n(i) *(1-n(i)) - beta_n(i) * n(i)); %Equation 7
    m(i+1) = m(i) + deltaT*(alpha_m(i) *(1-m(i)) - beta_m(i) * m(i)); %Equation 15
    h(i+1) = h(i) + deltaT*(alpha_h(i) *(1-h(i)) - beta_h(i) * h(i)); %Equation 16

end


V = V-70; %Set resting potential to -70mv

%===plot Voltage===%
plot(t,V,'LineWidth',3)
hold on
legend({'voltage'})
ylabel('Voltage (mv)')
xlabel('time (ms)')
title('Voltage over Time in Simulated Neuron')


%===plot Conductance===%
figure
p1 = plot(t,gbar_K*n.^4,'LineWidth',2);
hold on
p2 = plot(t,gbar_Na*(m.^3).*h,'r','LineWidth',2);
legend([p1, p2], 'Conductance for Potassium', 'Conductance for Sodium')
ylabel('Conductance')
xlabel('time (ms)')
title('Conductance for Potassium and Sodium Ions in Simulated Neuron')
